| Max. capacity | 4000 kg |
| Max. lifting height | 13.8 m |
| Max. outreach | 7 m |
| Overall length to carriage | 6.4 m |
| Length to face of forks | 7.62 m |
| Overall width | 2.4 m |
| Overall height | 2.55 m |
| Wheelbase | 3.15 m |
| Ground clearance | 0.38 m |
| Overall cab width | 0.84 m |
| Tilt-up angle | 12° |
| Tilt-down angle | 114° |
| External turning radius(over tyres) | 4.1 m |
| Unladen weight(with fork) | 10900 kg |
| Tires type | Tubeless |
| Standard tires | 440/80-24 |
| Forks length/ width/ section | 1220 mm x 125 mm / 50 mm |
| Lifting | 16 s |
| Lowering | 12.4 s |
| Extension | 17.3 s |
| Retraction | 13 s |
| Crowd | 4.3 s |
| Dump | 4 s |
| Engine brand | Yuchai (Optional Brand) |
| Engine norm | National ll |
| Max. fuel sulphur content | 5000 ppm |
| Engine model | YCD4J22T-125 |
| Number of cylinders / Capacity of cylinders | 4-4400 cm3 |
| I.C.Engine power rating -Power | 114 Hp / 85 kW |
| Max. torque / Engine rotation | 400 Nm @ 1400 rpm |
| Drawbar pull (Laden) | 9930 daN |
| Transmission type | Torque Converter (Optional Hydrostatic) |
| Number of gears (forward / reverse) | 4/4 |
| Max. travel speed | 40 km/h |
| Parking brake | Automatic Air-Cut Brake (Optional Wet Brake) |
| Service brake | immersed multi-discs braking on front & rear axles |
| Hydraulic pump type | Gear Pump (Optional Piston Pump) |
| Hydraulic flow / Pressure | 167 l/min -265 bar |
| Engine oil | 5.5L |
| Hydraulic oil | 70L |
| Fuel tank | 95L |
| Noise at driving position (LpA | 79 dB |
| Noise to environment(LwA) | 106 dB |
| Vibration on hands / arms | <2.50 m/s2 |
| Steering wheels (front / rear) | 2/2 |
| Drive wheels (front / rear) | 2/2 |
| Safety cab homologation | FOPS level 2 cab |
